Type 400康气通品牌产品总代理，（ Controlair康气通通用调压阀办事处）General Service Pressure Regulator Reliable, all purpose air regulation The Control Air Type 400 is a general purpose regulator designed to provide reliable performance under variable operating conditions. This quality unit is ideal as an economical alternative for control of industrial process applications. The regulation characteristics of the Type 400 have been proven to be superior to comparable competitive units. Durable materials and corrosion resistant construction provide reliable operation in harsh industrial environments. F E A T U R E S •Stable Output and Reliability Consistently meets control requirements under changing operating conditions •Corrosion Resistant Contruction Die-cast housings are finished with irridite and epoxy paint •Low Droop at High Flow Levels Aspirator design helps maintain set pressure and minimize “droop” at higher flow levels •High Quality Level Each regulator receives a pressure, leak and flow test at the factory prior to shipment •Low Cost This economical unit is ideal for high volume OEM applications Specifications Flow Capacity 20 SCFM (570 Nl/min) at 100 psig (6.8 BAR) supply - 20 psig (1.4 BAR) outlet Exhaust Capacity 0.1 SCFM (2.8 Nl/min)-downstream pressure 5 psig (0.3 BAR) above set point Sensitivity 1" (2.5 cm) of water Effect of Supply Less than 0.2 psig (0.01 BAR) Pressure Variation for 25 psi (1.7 BAR) change Max. Supply Pressure 250 psig (17 BAR) Air Consumption Less than 6 SCFH (170 Nl/min) Output Range 0-10 psig (0-0.7 BAR), 0-30 psig (0-2 BAR), 0-60 psig (0-4 BAR), 0-120 psig (0-8 BAR) Port Size 1/4" NPT Mounting Pipe or panel Materials Body: diecast aluminum alloy Diaphragm: nitrile elastomer and nylon fabric Trim: brass, zinc plated steel, acetal Weight 0.84 lb (0.38 kg) Temperature Limits 0˚ to 160˚F (-18˚ to 71˚C) Type 400 Dimensions P/N 441-625-004 08/15/12 2 4 6 8 10 12 14 16 18 20 22 24 26 28 (57) (113) (170) (226) (283) (340) (396) (453) (509) (566) (623) (679) (679) (736) 0-120 (0-8) 0-60 (0-4) 0-30 (0-2) FLOW, scfm (nl/min) 100 psig (6.9 BAR) supply OUTPUT psig (BA R) 80 (5.6) 70 (4.5) 60 (4.2) 50 (3.5) 40 (2.8) 30 (2) 20 (1.4) 10 (0.7) 0 Port Size Output Range Type (NPT) psi BAR 400-BD 1/4" 0-10 0-0.7 400-BA 1/4" 0-30 0-2 400-BB 1/4" 0-60 0-4 400-BC 1/4" 0-120 0-8 Options Add proper letter onto end of model number J - Low Temperature: temperature range -40˚ to 125˚F (-40˚ to 81˚C) K - Knob: to replace square head adjust screw N - Non-Relieving: for constant flow or downstream pressure relief applications E - Tapped Exhaust: allows captured exhaust 1/4" NPT port T - Tamperproof Cover: prevents casual adjustment of output pressure S - Stainless Steel Adjust Screw: hex head stainless steel adjust screw for maximum corrosion resistance V - Viton Elastomers: used where elements in the supply air are particularly destructive to standard Buna-N pintle and diaphragm material X - ATEX: 94/9EC Approval II 2 G D Accessories G - Pressure Gauge: 2" face, back mounted. When specified with the regulator the correct range will be supplied. Range P/N 0-15 446-725-003 0-30 446-725-004 0-60 446-725-001 0-160 446-725-002 B - Mounting Bracket: zinc-plated steel bracket for side mounting P/N: 446-707-028 Warranty ControlAir, Inc. products are warranted to be free from defects in materials and workmanship for a period of eighteen months from the date of sale, provided said products are used according to ControlAir, Inc. recommended usages. ControlAir, Inc.'s liability is limited to the repair, purchase price refund, or replacement in kind, at ControlAir, Inc.'s sole option, of any products proved defective. ControlAir, Inc. reserves the right to discontinue manufacture of any products or change products materials, designs or specifications without notice. Note: ControlAir does not assume responsibility for the selection, use, or maintenance of any product. Responsibility for the proper selection, use, and maintenance of any ControlAir product remains solely with the purchaser and end user. Flow Characteristics Ordering Type 400 Informatio
